Section 8
High Pressure Water System
20479291
2-2012/Rev 04
8-6
Table 8-1
Torque Specifications
High Pressure Water System
Stem Mount
Socket Head Screws 4 (M10) each
Torque 60-65 ft-lbs (80-88 Nm)
Hex Key M8
Sealing Head
Discharge Gland Nut 130 ft-lbs (176 Nm)
Poppet Retainer 30 in-lbs (3.4 Nm)
3-Port Pneumatic Valve
HP Adapter 25 ft-lbs (34 Nm)
1/4-inch Outlet to Drain 25 ft-lbs (34 Nm)
Pneumatic Actuator 5 ft-lbs (7 Nm)
3/8-inch HP Gland Nut 50 ft-lbs (68 Nm)
High Pressure Fittings
1/4-inch HP Gland Nut 25 ft-lbs (34 Nm)
3/8-inch HP Gland Nut 50 ft-lbs (68 Nm)
9/16-inch HP Gland Nut 110 ft-lbs (149 Nm)
