Section 11
Parts List
20479307
2-2012/Rev 04
11-13
Table 11-7
Hydraulic Power Package
20479025
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 80087935 Motor/Pump Assembly 1 11 10069714 Flat Washer, .38 2
2 05049168 Adapter, Water Pump 1 12 20437164 Directional Control Valve 1
3 95572897 Hex Head Screw, 1/4-20 x 5/8 3 13 95055059 Socket Head Screw, 1/2-13 x 2-1/2 6
4 95838314 Lock Washer, .25 3 14 95688750 Lock Washer 6
5 49887094 Vane Pump 1 15 10091510 Decal, Arrow 1
6 05071717 Relief Valve 1 16 10079036 Hose Barb, .50 x .38 2
7 10092302 Shaft Coupling 1 18 20432331 Socket Head Screw, M16 x 2 4
8 10116952 Cap plug 2 19 49833072 Lock Washer, .63 4
9 95750394 Lock Washer, .38 2 20 10142644 Adapter, JIC/ORB, .25 x .25 2
10 95416319 Hex Head Screw, 3/8-16 x 1 2 21 10144749 Adapter, JIC/ORB, .25 x .25 2
To Next Page
