Section 11

Parts List

20479307

2-2012/Rev 04

11-17

Table 11-9

Hydraulic Manifold Assembly

05071766

Item

Part

Number Description Quantity

1 05044144 Hydraulic Manifold 1

2 05071055 Plug, ORB, .75 1

3 05055017 Plug, ORB, .13 2

4 10185585 Solenoid Valve, 24V DC 1

5 10187052 Relief Valve, 25-3000 psi 1

6 10187060 Relief Valve, 25-1500 psi 1

7 49889744 Retainer, Cartridge Valve 1

8 49889736 Check Valve 1

9 49889769 Plug, ORB, .25 1
