Section 11
Parts List
20479307
2-2012/Rev 04
11-21
Table 11-11
Reservoir Assembly
20477002
Item
Part
Number Description Quantity Item
Part
Number Description Quantity
1 20454042 Reservoir Weldment 1 11 80087687 Diffuser, Return Line 1
2 20454105 Reservoir Lid 1 12 10085033 Plug, Pipe, .75 1
3 20462991 Gasket 95.0" 13 20423326 Ball Valve, 2-Way 1
4 20451474 Gauge, Level/Temperature 1 14 05025176 Plug, ORB, .50 1
5 05057542 Coupling, ORB, .75 x .75 1 15 10142644 Adapter, JIC/ORB, .25 x .25 1
6 05049697 Filter Head, Hydraulic 1 16 49876089 Adapter, JIC/ORB, .25 x .25 1
7 05049689 Filter Element, Hydraulic 1 17 95702619 Adapter, JIC/ORB, .75 x .75 1
8 05071063 Tee, JIC/ORB, .75 x .75 1 1 05092739 Air Breather 1
9 05069976 Cap, JIC Swivel 1 19 05050026 Temperature/Level Switch 1
10 05079371 Adapter, BSPP/JIC, .75 x .75 1 20 80085970 Adapter, JIC/ORB, 1.0 x 1.0 2
21 95738514 Hex Head Screw, 1/2-13 x 1 4
22 10075794 Flat Washer, .50 4
23 10170686 Lock Washer, .50 4
24 05060777 Elbow, JIC, .75 x .75 1
25 10082071 Pipe Plug, .38, not shown 1
