2.2.10.1. Programmable Input functions
At * the PGS leds are switched off every 4 seconds for 200 m.sec. to show the PGS is overruled by an input
Function Action Remark
Inactive Activating this input will not result in any action at all.
Open The door opens to the open position, a selection of Winter
opening will be ignored..
‘Ignore function when
Airlock active’ is ignored!
*Close and Lock The door will close, when no opening- or safety devices,
preventing the door from closing, are active. When the door
reaches its closed position the locking device will be activated, if
present, and the door will be locked.
*Close The door will close, when no opening- or safety devices,
preventing the door from closing, are active. When the door
reaches its closed position the locking device, if present and
activated, will be deactivated, and the door will be unlocked.
*Automatic The door will switch into the automatic mode, like in PGS
automatic. The door will stay in that position until the input is
inactive or a command with higher priority is detected.
*One Way The door will switch into the one way traffic mode, like in PGS
One Way. The door will stay in that position until the input is
inactive or a command with higher priority is detected..
*One Way locked The door will switch into the one way traffic mode, like in
Program switch One Way. Every time the closed position is
reached, the locking device (if present) will lock. On a valid
opening command, the door will first unlock, and than open.
Unlock When the locking device is present, and the door is locked, the
locking device will be de-activated and the door will stay
unlocked. The door will stay in that position until the input is
inactive or a command with higher priority is detected.
Sequential
opening ON
The selection ‘Sequential opening’ is set ON and visible on the
led above the sequence button on the PGS. If the selection was
already made on the PGS, this function doesn’t have effect.
Chemist opening. In preparation
SummerWinter
selection.
The selection ‘Winter opening’ is set ON and visible on the Led
above the winter button on the Program-switch. If the selection
was already made on the Program-switch, this function will have
no effect. Turning on the LED shows the PGS selection.
Raid alarm.
(active from vs
1.11)
The doors will close and lock, if present, immediately. All open
commands except NS and Porter, are inactive. Activated safety
reverse will stop the door 1 sec., and close further
Porter. An active input with this function will always open the door to
the selected open-position. The door will stay in that position
until the input is inactive or a command with higher priority.
Close, manual,
close after user
timer. (active
from version 1.12)
In this function the door will close, and the locking device, if
present and locked, will unlock. The unit will switch into manual
mode. When the door is opened by hand, the user timer is started.
After the user timer has timed out, the door will close again
automatically.
During closing, INSIDE,
OUTSIDE, NS, Porter and
Photocells will be active
Partially open The door will open until the winter opening position Winter timer is inactive
Safety Stop When this function is activated and the door is opening, the door
will stop immediately, and stay at that position until input is
released. No other setting are effected. Not allowed on RW
doors. Selecting the N.C. input, this function will also test the
sensor by combination with Photocell test signal. The input
should be active during Photocell test. The signal Photocell test
is also connected to the sensor
.
Only Raid alarm and
obstacle detection has
priority.
