KONE UniDrive
TM
service manual vs 9 51
2.9. Priority table
Priority number Function Generated by Remark
1 Emergency Stop Programmable input
2 Obstacle (open and close) Software
3 Obstacle (open and close) Programmable input Master/Slave application
4 Raid alarm Programmable input
4a Safety Sensor Stop Open Programmable input
4b Safety Sensor Slow Open Programmable input
8 Photocells Normal inputs
9 Close, unlock, manual Programmable input
10 Close, unlock, user-timer Programmable input
11 Emergency Open Programmable input
12 Porter open Programmable input
13 Night switch Normal input
14 Unlock Programmable input
15 Battery function Software setting
16 Mains Power failure Software setting
17 Easy Come in Software detection
18 Open timer Software setting
19 Close & lock Programmable input
Close Programmable input
Automatic Programmable input
One way Programmable input
One way with lock Programmable input
21 PGS Open Program switch 21: one function simultaneous
PGS automatic Program switch ,,
PGS One way Program switch ,,
PGS Closed Program switch ,,
22 Toilet mode Software setting
23 Airlock (Seq. Open) Programmable input
24 PGS Airlock (Seq. Open) Program switch
25 Inside and Outside Normal inputs
26 Partial open Programmable input Also called ‘nurse opening’
28 PGS winter position Program switch
29 Chemist lock Programmable input
2.9.1. Code repair parts
Year Code Month Code
2001 A January A
2002 B february B
2003 C March C
2004 D April D
2005 E May E
2006 F June F
2007 G July G
2008 H August H
2009 K September K
2010 L October L
2011 M November M
2012 N December N
Etc.
Example:
New April 2001 = AD
Next code is for Rep. dep.
1 - 9 = number x in repair .
Date of repair = see left code
New :
july 2005 rep. Jan 2006 = EG1FA
