2.2.11. Programmable outputs
Output 1 up to Output 5 can be programmed with the PSION programmer.
2.2.11.1. Programmable output functions
Programmable output functions
Function Action Remarks
Inactive None
Bell signal in/out When the Photocells are activated and the door is not closed,
this output is activated.
Stop active When the door has stopped because of activating the STOP
function, this will be signalled, by activating this output.
Signal; Locked When the locking device is locked, this output will be activated
to indicate the lock status.
Signal; Automatic
(from vs 1.35)
Active, when the PGS is on position “automatic”, or an Input is
programmed on position “automatic”
Signal; One way
(from vs 1.35)
Active, when the PGS is on position “one way”, or an Input is
programmed on position “one way”
Signal; Closed
(from vs 1.35)
Active, when the PGS is on position “closed”, or an Input is
programmed on position “closed”
Signal; Open
(from vs 1.35)
Active, when the PGS is on position “open”, or an Input is
programmed on position “open”
Elevator call
(from vs 1.35)
The output will be activated when the door is opened by either
Porter (or NS in Portermode) or Outside
An additional time delay could be set, Elevator Call Delay that
will delay the activation of the output. This could be useful
when door and elevator are not close to each other. The output
is activated for 3 seconds. Re-activating of the output will only
be done when the door has reached its closed position again, to
avoid repeated Elevator Call signals
Output sequence Is active when the door is not closed
Bell signal
Incoming traffic
When the Photocells are activated within 3 seconds from the
moment OUTSIDE is activated and the door is not closed, this
output will be activated for 500mSec. This is used to signal
incoming traffic.
Error indication The output will be activated, when any kind of error is
detected.
Door closed.
Indication
When the door is at the closed position, this output will be
activated. The output will be deactivated, as soon as the door
will start to open.
Door open
indication
When the door reaches its opening position (not winter opening
position!), this output will be activated. The output will be
deactivated, as soon as the door will start to close
