KONE UniDrive
TM
service manual vs 9 26
2.2.11.2. Programmable output flags.
After selecting the desired output function, several additional setting can be made.
Programmable output function flags
Function Action Remarks
Pulsed When set, output will be activated with a repetitive on-off
signal.
From version 1.11 interval timer = usertimer x 50 m. sec.
When speech module is activated then the output pulse is
defined as follows:
Pulse time = usertimer x 10 m.sec..
Pulse delay = usertimer sec.
NO/NC (inverted) When set, output will be switched on, at the selected event,
otherwise it will be switched off at the selected event.
2.2.12. Software settings.
In addition to the above mentioned programmable inputs and outputs, several selections and settings can be made
by the use of the PSION programmer software.
Also a lot of parameters (for example speed, timer functions) which are used by the UniDrive
TM
control box can be
modified by the user with the help of the PSION programmer.
2.2.12.1. Speed settings.
Speed settings
Function Max/Min value Action Remarks
Open speed
15-100 %
Maximum speed used to open the
sliding door.
Limited by UniDrive
TM
control unit, depends on
measured door-weight.
Close speed
15-100 %
Maximum speed used to close the
sliding door.
Limited by UniDrive
TM
control unit ( door-weight)
2.2.13. Timer settings
In the UniDrive
TM
software several timers are available, which can be set by the user.
Function Max/Min value Action Remarks
Open hold timer 0 - 60 Sec Timer to keep door in the open position,
after receiving last open command., and
starts, when open-position is reached.
Timer will restart after each
open-command
Delay Winter
position
0 - 60 Sec Timer starts when winter-position is
reached. After delay the winter position
is counted down and the UniDrive
TM
will switch to maximum open-position.
When 0 Sec selected,
UniDrive
TM
will NEVER
switch to maximum open-
position on timer.
Delay Sequential
opening
0 - 60 Sec Timer starts when door receives an open
command and incoming Sequence
Opening signal. After sequence opening
delay, UniDrive
TM
will open, even if
interlock has overwrites.
When 0 Sec selected,
UniDrive
TM
will NEVER
ignore Seq. Opening signal
on timer.
User timer
(from vs 1.11.
5 - 100 sec User timer is needed for several in- and
output functions (pulsed) and is the
timer for the “auto close function”
Lock delay timer
(from vs 1.11.
0 - 100 % Time between unlock start action and
start of the door open cycle
Elevator Call delay
(from vs 1.35)
0 – 100 sec. Time between input activation and
starting output to call elevator
Activate NS/outside
