Konica Minolta 7155 - Input Checklist

47 MODE
1 ADJUSTMENT
[4] Input checklist
Classi-
fication
Code Symbol
Multi
mode
Name
Display and
Signal Source
HL
Analog signal
001 TLD
Remaining toner detection signal
In Empty
002 VR301
ADF original size VR signal
0 to 255
003 TH1
Fixer upper roller temperature detection signal
004
Fixer upper roller temperature
°
C
005
Humidity sensor signal
0 to 255
006
Dmax MONI signal
007
Dmax signal
008
γ
signal
009
Machine inside temperature signal
Paper feed
011
PS3 1
Tray 1 no paper detection signal
ON OFF
PS9 2
Tray 2 no paper detection signal
PS15 3
Tray 3 no paper detection signal
PS21 4
Tray 4 no paper detection signal
PS33 5
By-pass feed tray no paper detection signal
PS108 6
LCT no paper detection signal
012
PS4 1
Tray 1 remaining paper detection signal
PS10 2
Tray 2 remaining paper detection signal
PS16 3
Tray 3 remaining paper detection signal
PS22 4
Tray 4 remaining paper detection signal
PS102 5
LCT remaining paper detection signal 1
PS103 6
LCT remaining paper detection signal 2
PS104 7
LCT remaining paper detection signal 3
PS105 8
LCT remaining paper detection signal 4
013
PS5 1
Tray 1 paper size detection signal 1(7155/7165 only)
PS6 2
Tray 1 paper size detection signal 2(7155/7165 only)
PS11 3
Tray 2 paper size detection signal 1(7155/7165 only)
PS12 4
Tray 2 paper size detection signal 2(7155/7165 only)
PS17 5
Tray 3 paper size detection signal 1
PS18 6
Tray 3 paper size detection signal 2
-7
-
-8
-
PS31 9
By-pass feed tray paper size detection signal 1
PS32 10
By-pass feed tray paper size detection signal 2
014
VR1 1
Tray 1 paper size detection VR signal
(7155/7165 only)
0 to 255
VR2 2
Tray 2 paper size detection VR signal
(7155/7165 only)
VR3 3
Tray 3 paper size detection VR signal
-4
-
VR5 5
By-pass feed tray paper size detection VR signal
015
1
Tray 1 paper size signal
(7155/7165 only)
0:11x17,1:A3,2:B4,3:8.5x14,4:A4R,5:8.5x11
R,6:B5R,7:8.5x11,8:5.5x8.5R,9:A4,10:A5R1
1:B5,12:A5,13:B6R,14:5.5x8.5,15:B6,16:Sp
esial,17:F4(8.125x13.25),18:F4(8x13),19:F4
(8.25x13),20:F4(8.5x13)
2
Tray 2 paper size signal
(7155/7165 only)
3
Tray 3 paper size signal
4
-
5
By-pass feed tray paper size signal
4
4
4
