1 OUTLINE
[5] Bypass Paper Feed /ADU Pre-Registration Drive Section
Paper feed roller
Feed roller
Loop roller
Loop roller motor (M6)
ADU pre-registration roller
Up/down motor/BP (M20)
Paper up/down
plate
