MAIN BODY
1-12
1 OUTLINE
In the case of the 7255/7272
7272ma1003
Feed roller
Paper feed roller
Pre-registration MC
(MC4/6/8/10)
Pre-registration roller
Double feed prevention roller
Tray 1/2/3/4
Drive belt
Drive belt
Vertical conveyance MC/1 (MC11)
Horizontal conveyance
roller/R
Horizontal conveyance
MC/R (MC16)
Horizontal conveyance
MC/L (MC15)
Vertical conveyance roller (upper)
Vertical conveyance MC/2 (MC12)
Vertical conveyance roller (middle)
Paper feed motor (M1)
Up/down plate
Tray up drive motor/1 (M16)
Tray up drive motor/2 (M17)
Tray up drive motor/3 (M18)
Tray up drive motor/4 (M19)
Paper feed MC
(MC3/5/7/9)
Horizontal conveyance
roller/L
Vertical conveyance roller (lower)
4
MODEL MANUAL REVISED EDITION DATE PAGE METHOD
SERVICE MANUAL Dec. 2003
7155/7165/7255/7272
1-7-1 ADDITION
4
