10. SERVICE MODE
208
Field Service Ver.2.0 Mar. 2009
bizhub 501/421/361
10.6.2 Present Parts Life
Displays the counter of an intended part.
And, when replacing an intended part, the counter of the replaced part is reset to manage the service history.
A. Procedure for the display/reset
B. Fixed parts counter list
1.
"Service Mode screen"
Press [Counter].
2.
"Counter/Data screen"
Press [Present Parts Life].
3.
"Parts Counter (Fixed) screen"
Press [ ↑ ]/[ ↓ ] to check the counter or display a part to be reset.
4.
"Parts Counter (Fixed) screen"
Check the count value of an intended part.
When resetting it, press a part to be reset and then press the Clear key.
5.
Press [OK].
No. CSRC
parameter
(Z1)
Unit Parts name Parts No.
1 00 DC (including charge unit) Drum —
2 01 Cleaning blade assy 50GA-209
3 02 Drum unit (including charge unit) 50GA-200
4 03 Transfer/separation section Transfer/separation unit 50GA-260
5 04 Developing unit Developer —
6 05 Developing unit 50GA-300
7 06 Main body Filter mounting plate assy 50GA-336
8 07 Ozon filter 50GA1031
9 08 Suction filter /A assy 40LA-318
10 09 Filter cover assy 50GA-314
11 0A Suction cover /2 assy 50GA-311
12 0B Paper feed unit Tray 1 pick-up roller 40303005
13 0C Tray 1 paper feed roller 40303005
14 0D Tray 1 separation roller 40300151
15 0E Tray 2 pick-up roller 40303005
16 0F Tray 2 paper feed roller 40303005
17 10 Tray 2 separation roller 40300151
18 11 Bypass unit Bypass paper feed roller 41313001
19 12 Bypass separation roller 40340151
20 13 Registration section Paper feed connection roller 50GA3865
21 14 Registration roller /A 50GA3848
22 15 Registration bearing /1 26NA4536
23 16 Registration bearing /2 26NA4537
24 17 Paper feed slide bearing 26NA4082
To Next Page
