Konica Minolta bizhub 501 Service Manual

bizhub 501/421/361
12. JAM CODE
327
Field Service Ver.2.0 Mar. 2009
 TROUBLESHOOTING
12. JAM CODE
12.1 Jam code list
Classification Jam code Cause Resulting
operation
Correction
Bypass J-1000
During operation
The vertical conveyance sensor (PS2)
does not turn ON within a specified
period of time after the feed clutch
/BP (CL6) turns ON.
If there is a
sheet of paper
being printed
when a jam
occurs, the main
body completes
the paper exit
before stopping
operations.
Pull out the paper from
the bypass tray and
remove jammed paper
if any.
Tray 1 J-1100 The registration sensor (PS1) does
not turn ON within a specified period
of time after the feed clutch /1 (CL4)
turns ON.
Open the vertical con-
veyance door and ADU
and remove jammed
paper if any.
Pull out the tray and
remove jammed paper
if any.
Tray 2 J-1200 The vertical conveyance sensor (PS2)
does not turn ON within a specified
period of time after the feed clutch /2
(CL5) turns ON.
J-1201 The registration sensor (PS1) does
not turn ON within a specified period
of time after the vertical conveyance
sensor (PS2) turns ON.
PC-206 J-1300 The vertical conveyance sensor /3
(PS117) does not turn ON a specified
period of time after the paper feed
motor /3 (M122) turns ON.
Open the right door of
PC and the vertical
conveyance door of the
main body and remove
jammed paper if any.
Pull out the tray and
remove jammed paper
if any.
PC-407 The vertical conveyance sensor (PS2)
does not turn ON a specified period
of time after the paper feed motor
(M1) turns ON.
PC-206 J-1301 The vertical conveyance sensor (PS2)
of the main body does not turn ON
within a specified period of time after
the vertical conveyance sensor /3
(PS117) of PC-206 turns ON.
PC-407 J-1302 The vertical conveyance sensor (PS2)
of the main body does not turn ON
within a specified period of time after
the vertical conveyance sensor (PS2)
of PC-407 turns ON.
J-1305 The paper feed sensor (PS1) does not
turn ON within a specified period of
time after the paper feed motor (M1)
turns ON.

Konica Minolta bizhub 501 Specifications

General

Type	All-in-One Printer
Functions	Print, Copy, Scan, Fax
Print Speed (Black)	50 ppm
Print Resolution	1200 x 1200 dpi
Max Resolution (B&W)	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Speed (Black)	50 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Paper Capacity	1, 150 sheets
Max Paper Capacity	5, 650 sheets
Automatic Duplexing	Yes
Duplex Printing	Yes
Connectivity	USB, Ethernet
Network Connectivity	Yes
Operating System Compatibility	Windows, Mac, Linux
Maximum Paper Size	11 x 17 inches
