3-8 Konica 7115/7118
Inside the Copier
No. Part Name Description
1 Imaging Unit Forms a copy image.
The Imaging Unit is to be replaced only by your authorized Konica
Service Representative.
2 Toner Bottle Holder Open to replace the Toner Bottle.
3 Pressure Lever Use to clear a misfed sheet of paper at the Fusing Unit. (p.8-12)
