Loading Originals
4
Konica 7115/7118 4-1
4 Loading Originals
4.1 Two Ways to Load the Original
The original may be loaded in the Automatic Document Feeder or placed directly on the Platen
Glass. Choose the appropriate method according to the type of the original.
Specific Types of Originals
Original Loading Original Type Original Size
Automatic Document Feeder Sheet originals
• Weight of originals: 13-1/4 lbs. to
29-1/4 lbs.
• Weight of originals of mixed sizes:
16 lbs. to 24 lbs.
11×17L to InvoiceL
• Original width: 3-9/16 in. to 11-11/16 in.
• Original length: 8-1/4 in. to 17 in.
Platen Glass Max. weight of sheet originals,
books, or three-dimensional objects:
6-1/2 lbs.
11×17L to Invoice
• Original width: Up to 11-11/16 in.
• Original length: Up to 17 in.
