Before Making Copies
3
Konica 7115/7118 3-11
Shifting Unit
Job Tray
No. Part Name Description
12 Copy Tray Receives copy sets sorted.
No. Part Name Description
13 Copy Tray Indicator Lights up when paper is fed into the Upper Copy Tray.
14 Upper Copy Tray Receives printed pages produced via the personal computer or
faxes received.
15 Lower Copy Tray Receives copies made.
15
14
13
12
When Job Tray is Mounted
