Reference • Arrangement Play mode
82
Page 18: Tone programming (Guitar mode)
[Parameters memorised in the Keyboard Set]
This page contains the programming of the Tone effect
selected in “Page 16: Guitar effects (2) (Guitar mode)”
(see page 74).
Note: These parameters can only be accessed if the
TONE parameter is not set on OFF in “Page 16: Guitar
effects (2) (Guitar mode)”.
The Tone section is composed of an equalizer with
three fixed bands. The bands are Lo, Md, and Hi.
Lo
[-15…0…+15]
Low frequency band. With positive values the band is
boosted (level increase), whereas with negative values
the band is cut (level reduction).
Md
[-15…0…+15]
Medium frequency band. With positive values the
band is boosted (level increase), whereas with nega-
tive values the band is cut (level reduction).
Hi
[-15…0…+15]
High frequency band. With positive values the band is
boosted (level increase), whereas with negative values
the band is cut (level reduction).
Page 19: Drive programming (Guitar mode)
[Parameters memorised in the Keyboard Set]
This page shows the parameters of the DRV (Drive)
effect selected in “Page 15: Guitar effects (1) (Guitar
mode)”. The parameters are different according to the
selected effect.
Note: These parameters can only be accessed if the DRV
parameter is not set on OFF in “Page 15: Guitar effects
(1) (Guitar mode)”.
Overdrive
The overdrive is a distorsion with warm dense sounds,
obtained by simulating the saturation of the pre-
amplification stage of the amplifier.
Gain
[0…30]
Gain (overdrive saturation).
Level
[0…30]
Effect level.
MODE
ARR.PLAY
OCTAVETEMPO
PAGE
CHORD
M
7
MODE
ARR.PLAY
OCTAVETEMPO
PAGE
CHORD
M
7
