Korg Triton Studio User Manual

236
097: Early Reflections
This early reflection effect has more precise early reflections
with twice the maximum length of a normal-size effect
(Fx:041). You can create a very smooth and dense sound.
098: L/C/R Long Delay
This multitap delay outputs three Tap signals to left, right and
center respectively. You can set a maximum of 2,730msec for
the delay time.
099: St/Cross Long Dly
(Stereo/Cross Long Delay)
This is a stereo delay, and can by used as a cross-feedback
delay effect in which the delay sounds cross over between left
and right by changing the feedback routing. You can set a
maximum of 1,360msec for the delay time.
a
Type Sharp, Loose, Modulated, Reverse
Selects the decay curve for the early reflection
☞ Fx:041
b
ER Time [msec]
Sets the time length of early reflection
10...1600msec
c
Pre Delay [msec] 0...200msec
Sets the time taken from the original sound to the first early reflection
d
EQ Trim 0...100
Sets the input level of EQ applied to the effect sound
e
Pre LEQ Gain [dB]
Sets the gain of Low EQ
–15.0...+15.0dB
Pre HEQ Gain [dB]
Sets the gain of High EQ
–15.0...+15.0dB
f
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
a
L Delay Time [msec]
Sets the delay time of TapL
0...2730msec
Level
Sets the output level of TapL
0...50
b
C Delay Time [msec]
Sets the delay time of TapC
0...2730msec
Level
Sets the output level of TapC
0...50
c
R Delay Time [msec]
Sets the delay time of TapR
0...2730msec
Level
Sets the output level of TapR
0...50
d
Feedback (C Delay)
Sets the feedback amountof TapC
–100...+100
Src Off...Tempo
Selects the modulation source of the TapC feedback amount
Amt –100...+100
Sets the modulation amount of the TapC feedback amount
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
EQ Trim
+
EQ Trim
Pre Delay
Early Reflections
LEQ HEQ
C Delay
R Delay
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
Input Level D-mod
High Damp Low Damp
L Delay
Input Level D-mod
+
Level
Level
Level
e
High Damp [%]
Sets the damping amount in the high range
0...100%
☞ Fx:043
Low Damp [%]
Sets the damping amount in the low range
0...100%
☞ Fx:043
f
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
g
Spread 0...50
Sets the width of the stereo image of the effect sound
☞ Fx:043
h
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
a
Stereo/Cross Stereo, Cross
Switches between stereo delay and cross-feedback delay
b
L Delay Time [msec]
Sets the delay time for the left channel
0.0...1360.0msec
c
R Delay Time [msec]
Sets the delay time for the right channel
0.0...1360.0msec
d
L Feedback
Sets the feedback amount for the left channel
–100...+100
Src Off...Tempo
Selects the modulation source of feedback amount
Amt L –100...+100
Sets the modulation amount of the left channel feedback
e
R Feedback
Sets the feedback amount for the right channel
–100...+100
Amt R –100...+100
Sets the modulation amount of the right channel feedback
f
High Damp [%]
Sets the damping amount in the high range
0...100%
☞ Fx:043
g
Low Damp [%]
Sets the damping amount in the low range
0...100%
☞ Fx:043
h
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
i
Spread –50...+50
Sets the width of the stereo image of the effect sound
☞ Fx:043
j
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
Delay
Delay
Stereo/Cross
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Spread
Stereo/Cross

Korg Triton Studio Specifications

General

MIDI	In, Out, Thru
Type	Workstation
Polyphony	62 voices
Oscillators	2 oscillators per voice
Effects	2 master effects
Sequencer	16-track
Sampling	16-bit, 48 kHz, expandable RAM (optional EXB-SMPL board)
Display	TouchView graphical interface
Storage	Internal hard drive, floppy disk drive
Keyboard	61, 76, or 88 keys with velocity and aftertouch
Sound ROM	32 MB (expandable with EXB series)
Outputs	stereo main outputs
Inputs	L/Mono, R
