Korg Triton Studio User Manual

86
9–2: MFX 1
9–3: MFX 2
Here you can set the parameters of the MFX 1 and 2 effects
that were selected in the Master FX page (☞p.187–).
9–2(3)a: Ctrl Ch
Ctrl Ch [Ch01...16, Gch]
Specifies the MIDI channel that will control dynamic
modulation (Dmod) for the master effects. If Gch is
selected, the global MIDI channel “MIDI Channel”
(Global P1: 1–1a) will be used.
9–4: Master EQ
The master EQ is a three-band stereo EQ. It is used to per-
form overall equalizing (tonal adjustment) on the sound
from the L/R bus immediately before it is output to AUDIO
OUTPUT (MAIN OUT) L/MONO and R (☞p.239).
9–4a: Ctrl Ch
Ctrl Ch [Ch01...16, Gch]
Specifies the MIDI channel that will control dynamic
modulation (Dmod) for the master EQ. If Gch is
selected, the global MIDI channel “MIDI Channel”
(Global P1: 1–1a) will be used.
The MEQ High Gain and MEQ Low gain can be controlled
by assigning a modulation source to the “Low Gain Mod-
Src:” and the “High Gain Mod-Src:” functions on this page.
9–1
9–2a
0–1A
9–4a

Korg Triton Studio Specifications

General

MIDI	In, Out, Thru
Type	Workstation
Polyphony	62 voices
Oscillators	2 oscillators per voice
Effects	2 master effects
Sequencer	16-track
Sampling	16-bit, 48 kHz, expandable RAM (optional EXB-SMPL board)
Display	TouchView graphical interface
Storage	Internal hard drive, floppy disk drive
Keyboard	61, 76, or 88 keys with velocity and aftertouch
Sound ROM	32 MB (expandable with EXB series)
Outputs	stereo main outputs
Inputs	L/Mono, R
