Korg Triton Studio User Manual

Effect
237
100: LCR BPM Long Dly
(L/C/R BPM Long Delay)
The L/C/R delay enables you to match the delay time with
the song tempo. You can set the delay time up to 2,730msec.
a: Time Over? >
You can set the delay time up to 2,730msec. If the delay time
exceeds this limit, the error message “OVER!!” appears on the dis-
play. Set the delay time parameters so that this message will not
appear. "Time Over?>" is only a display parameter.
101: St. BPM Long Delay
(Stereo BPM Long Delay)
The stereo delay enables you to match the delay time with the
song tempo. You can set the delay time up to 1365msec.
a
BPM MIDI, 40...240
Selects MIDI Clock and assigns tempo
☞ Fx:049,
Time Over? > ----, OVER!!
Displays an error message when the delay time exceeds the upper
limit
☞
b
L Delay Base Note
                 
Selects the type of notes to specify the delay time for TapL
☞ Fx:049,
Times x1...x16
Sets the number of notes to specify the delay time for TapL
☞ Fx:049
Level
Sets the output level of TapL
0...50
c
C Delay Base Note
                 
Selects the type of notes to specify the delay time for TapC
☞ Fx:049,
Times x1...x16
Sets the number of notes to specify the delay time for TapC
☞ Fx:049
Level
Sets the output level of TapC
0...50
d
R Delay Base Note
                 
Selects the type of notes to specify the delay time for TapR
☞ Fx:049,
Times x1...x16
Sets the number of notes to specify the delay time for TapR
☞ Fx:049
Level
Sets the output level of TapR
0...50
e
Feedback (C Delay)
Sets the feedback amount of TapC
–100...+100
Src Off...Tempo
Selects the modulation source for the TapC feedback
Amt –100...+100
Sets the modulation amount of the TapC feedback
f
High Damp [%]
Sets the damping amount in the high range
0...100%
☞ Fx:043
Low Damp [%]
Sets the damping amount in the low range
0...100%
☞ Fx:043
g
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
h
Spread 0...50
Sets the width of the stereo image of the effect sound
☞ Fx:043
i
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
C Delay
R Delay
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
Input Level D-mod
High Damp
Low Damp
L Delay
Input Level D-mod
+
Level
Level
Level
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Base Note x Times
a
BPM MIDI, 40...240
Selects MIDI Clock and assigns tempo
☞ Fx:049,
Time Over? L > ----, OVER!!
Display the error message if the left channel delay time exceeds the
upper limit
☞
R > ----, OVER!!
Display the error message if the right channel delay time exceeds the
upper limit
☞
b
L Delay Base Note
                 
Selects the type of notes to specify the left channel delay time
☞ Fx:049,
Times x1...x16
Sets the number of notes to specify the left channel delay time
☞ Fx:049
Adjust [%]
Fine-adjust the left channel delay time
–2.50...+2.50%
c
R Delay Base Note
                 
Selects the type of notes to specify the right channel delay time
☞ Fx:049,
Times x1...x16
Sets the number of notes to specify the right channel delay time
☞ Fx:049
Adjust [%]
Fine-adjust the right channel delay time
–2.50...+2.50%
d
L Feedback
Sets the feedback amount for the left channel
–100...+100
Src Off...Tempo
Selects the modulation source of feedback amount
Amt L –100...+100
Sets the modulation amount of the left channel feedback
e
R Feedback
Sets the feedback amount for the right channel
–100...+100
Amt R –100...+100
Sets the modulation amount of the right channel feedback
f
High Damp [%]
Sets the damping amount in the high range
0...100%
☞ Fx:043
g
Low Damp [%]
Sets the damping amount in the low range
0...100%
☞ Fx:043
h
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
Delay
Delay
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Tempo
BPM
BPM
Base Note x Times
Adjust [%]
Base Note x Times
Adjust [%]

Korg Triton Studio Specifications

General

MIDI	In, Out, Thru
Type	Workstation
Polyphony	62 voices
Oscillators	2 oscillators per voice
Effects	2 master effects
Sequencer	16-track
Sampling	16-bit, 48 kHz, expandable RAM (optional EXB-SMPL board)
Display	TouchView graphical interface
Storage	Internal hard drive, floppy disk drive
Keyboard	61, 76, or 88 keys with velocity and aftertouch
Sound ROM	32 MB (expandable with EXB series)
Outputs	stereo main outputs
Inputs	L/Mono, R
