Korg Triton Studio

270
2.RECOGNIZED RECEIVE DATA 2-1 CHANNEL MESSAGES [H] :Hex, [D] :Decimal Status Second | Third | Description ( Use ..... ) ENA | [Hex] [H] [D] | [H] [D] | | 8n kk (kk)| xx (xx) | Note Off A | 9n kk (kk)| 00 (00) | Note Off A | 9n kk (kk)| vv (vv) | Note On (vv)=1-127 A | An kk (kk)| vv (vv) | Poly Key Pressure ( as AMS ) T,Q| Bn 00 (00)| mm (mm) | Bank Select(MSB) ( for Prog/Combi change ) *1 P | Bn 01 (01)| vv (vv) | Modulation1 ( as Joy Stick +Y ) C | Bn 02 (02)| vv (vv) | Modulation2 ( as Joy Stick -Y ) C | Bn 04 (04)| vv (vv) | Foot Pedal ( as AMS & FX Dmod Src = Pedal ) C | Bn 05 (05)| vv (vv) | Portamento Time C | Bn 06 (06)| vv (vv) | Data Entry (MSB) ( for RPC edit ) C | Bn 07 (07)| vv (vv) | Volume C | Bn 08 (08)| vv (vv) | Balance Control ( for Post IFX Panpot control ) *2 C | Bn 0A (10)| vv (vv) | Panpot C | Bn 0B (11)| vv (vv) | Expression C | Bn 0C (12)| vv (vv) | E ffect Control 1 ( as FX Dmod Src = FxCtrl1 ) C | Bn 0D (13)| vv (vv) | Effect Control 2 ( as FX Dmod Src = FxCtrl2 ) C | Bn 10 (16)| vv (vv) | Multi Purpose Ctrl1 ( as Ribbon Controller ) C | Bn 11 (17)| vv (vv) | Multi Purpose Ctrl2 ( as AMS & FX Dmod Src = KnobMod1 ) C | Bn 12 (18)| vv (vv) | Multi Purpose Ctrl3 ( as Value Slider ) C | Bn 13 (19)| vv (vv) | Multi Purpose Ctrl4 ( as AMS & FX Dmod Src = KnobMod2 ) C | Bn 14 (20)| vv (vv) | ( as AMS & FX Dmod Src = KnobMod3 ) C | Bn 15 (21)| vv (vv) | ( as AMS & FX Dmod Src = KnobMod4 ) C | Bn 20 (32)| bb (bb) | Bank Select(LSB) ( for Prog / Combi change ) *1 P | Bn 26 (38)| vv (vv) | Data Entry (LSB) ( for RPC edit ) C | Bn 40 (64)| vv (vv) | Hold1 ( as Damper) C | Bn 41 (65)| ≤3F/≥40 (≤63/≥64) Portamento Off/On C Bn 42 (66)| ≤3F/≥40 (≤63/≥64) Sostenuto Off/On C Bn 43 (67)| vv (vv) | Soft Pedal C | Bn 46 (70)| vv (vv) | Sound Controller 1 ( for Sustain Level control ) C | Bn 47 (71)| vv (vv) | Sound Controller 2 ( for Resonance/HPF Cutoff ctrl ) C | Bn 48 (72)| vv (vv) | Sound Controller 3 ( for Release Time control ) C | Bn 49 (73)| vv (vv) | Sound Controller 4 ( for Attack Time control ) C | Bn 4A (74)| vv (vv) | Sound Controller 5 ( for LPF Cutoff control ) C | Bn 4B (75)| vv (vv) | Sound Controller 6 ( for Decay Time control ) C | Bn 4C (76)| vv (vv) | Sound Controller 7 ( for LFO1 Speed control ) C | Bn 4D (77)| vv (vv) | Sound Controller 8 ( for LFO1 Pitch Depth control ) C | Bn 4E (78)| vv (vv) | Sound Controller 9 ( for LFO1 Delay control ) C | Bn 4F (79)| vv (vv) | Sound Controller 10 ( for Filter EG Intencity ctrl ) C | Bn 50 (80)| vv (vv) | Multi Purpose Ctrl5 ( as AMS & FX Dmod Src = SW 1 ) C | Bn 51 (81)| vv (vv) | Multi Purpose Ctrl6 ( as AMS & FX Dmod Src = SW 2 ) C | Bn 52 (82)| vv (vv) | Multi Purpose Ctrl7 ( as AMS & FX Dmod Src = Foot SW ) C | Bn 53 (83)| vv (vv) | Multi Purpose Ctrl8 ( as AMS & FX Dmod Src = CC#83 ) C | Bn 5B (91)| vv (vv) | Effect 1 Depth ( for Send 2 Level control ) C | Bg 5C (92)| 00/≠00 (00/≠000) Effect 2 Depth ( for All Insert FX Off/On ) C Bn 5D (93)| vv (vv) | Effect 3 Depth ( for Send 1 Level control ) C | Bg 5E (94)| 00/≠00 (00/≠000) Effect 4 Depth ( for Master FX1 Off/On ) C Bg 5F (95)| 00/≠00 (00/≠000) Effect 5 Depth ( for Master FX2 Off/On ) C Bn 60 (96)| 00 (00) | Data Increment ( for RPC edit ) C | Bn 61 (97)| 00 (00) | Data Decrement ( for RPC edit ) C | Bn 62 (98)| ss (ss) | NRPN Param No.(LSB) ( for NRPN select ) *3 C | Bn 63 (99)| tt (tt) | NRPN Param No.(MSB) ( for NRPN select ) *3 C | Bn 64(100)| 0r (0r) | RPN Param No. (LSB) ( for RPN select ) *4 C | Bn 65(101)| 00 (00) | RPN Param No. (MSB) ( for RPN select ) *4 C | Bn cc (cc)| vv (vv) | Control data ( for Seq. recording (cc)=0-101 ) C,Q| Bn 78(120)| 00 (00) | All Sound Off C | Bn 79(121)| 00 (00) | Reset All Controllers C | Bn 7A(122)| 00/7F (00/127) | Local Control Off/On A | Bn 7B(123)| 00 (00) | All Notes Off A | Bn 7C(124)| 00 (00) | Omni Mode Off ( as All Notes Off ) A | Bn 7D(125)| 00 (00) | Omni Mode On ( as All Notes Off ) A | Bn 7E(126)| ≤10 (≤16) Mono Mode On ( as All Notes Off ) A Bn 7F(127)| 00 (00) | Poly mode On ( as All Notes Off ) A | Cn pp (pp)| -- -- | Program Change ( for Prog/Combi change ) *1 P | Dn vv (vv)| -- -- | Channel Pressure ( as After Touch ) T | En bb (bb)| bb (bb) | Bender Change C | AMS : Alternate Modulation Source FX Dmod Src: Effect Dynamic Modulation Source n : MIDI Channel No. (0 - 15) •••••• Usually Global Channel. When in Combination/Sequencer/Song Play mode, each timbre's/track's channel.(Status is INT or BTH) g : Always Global Channel No. (0 - 15) x : Random ENA : Same as Transmitted data
*1 : When Bank Map in Global mode is KORG; MIDI In [Hex] Program Combination mm,bb,pp = 00,00, 00 - 7F : Bank INT-A 000 - 127 : Bank INT-A 000 - 127 00,01, 00 - 7F : INT-B 000 - 127 : INT-B 000 - 127 00,02, 00 - 7F : INT-C 000 - 127 : INT-C 000 - 127 00,03, 00 - 7F : INT-D 000 - 127 : INT-D 000 - 127 00,04, 00 - 7F : INT-E 000 - 127 : INT-E 000 - 127 00,05, 00 - 7F : INT-F 000 - 127 00,08, 00 - 7F : EXB-A 000 - 127 : EXB-A 000 - 127 00,09, 00 - 7F : EXB-B 000 - 127 : EXB-B 000 - 127 00,0A, 00 - 7F : EXB-C 000 - 127 : EXB-C 000 - 127 00,0B, 00 - 7F : EXB-D 000 - 127 : EXB-D 000 - 127 00,0C, 00 - 7F : EXB-E 000 - 127 : EXB-E 000 - 127 00,0D, 00 - 7F : EXB-F 000 - 127 : EXB-F 000 - 127 00,0E, 00 - 7F : EXB-G 000 - 127 : EXB-G 000 - 127 79,00, 00 - 7F : G 001 - 128 79,01-09,00 - 7F : g(1)-g(9) 001 - 128 78,00, 00 - 7F : g(d) 001 - 128 38,00, 00 - 7F : G 001 - 128 3E,00, 00 - 7F : g(d) 001 - 128 When Bank Map in Global mode is GM(2); MIDI In [Hex] Program Combination mm,bb,pp = 3F,00, 00 - 7F : Bank INT-A 000 - 127 : Bank INT-A 000 - 127 3F,01, 00 - 7F : INT-B 000 - 127 : INT-B 000 - 127 3F,02, 00 - 7F : INT-C 000 - 127 : INT-C 000 - 127 3F,03, 00 - 7F : INT-D 000 - 127 : INT-D 000 - 127 3F,04, 00 - 7F : INT-E 000 - 127 : INT-E 000 - 127 3F,05, 00 - 7F : INT-F 000 - 127 3F,08, 00 - 7F : EXB-A 000 - 127 : EXB-A 000 - 127 3F,09, 00 - 7F : EXB-B 000 - 127 : EXB-B 000 - 127 3F,0A, 00 - 7F : EXB-C 000 - 127 : EXB-C 000 - 127 3F,0B, 00 - 7F : EXB-D 000 - 127 : EXB-D 000 - 127 3F,0C, 00 - 7F : EXB-E 000 - 127 : EXB-E 000 - 127 3F,0D, 00 - 7F : EXB-F 000 - 127 : EXB-F 000 - 127 3F,0E, 00 - 7F : EXB-G 000 - 127 : EXB-G 000 - 127 79,00, 00 - 7F : G 001 - 128 79,01-09,00 - 7F : g(1)-g(9) 001 - 128 78,00, 00 - 7F : g(d) 001 - 128 00,00, 00 - 7F : G 001 - 128 38,00, 00 - 7F : G 001 - 128 3E,00, 00 - 7F : g(d) 001 - 128 3F,7F, 00 - 7F : Mute (KORG MUTE) (XG) 00,01 - : Assign correspond program in G, g(1) - g(9) (GS) 01,00 - : Assign correspond program in G, g(1) - g(9) *2 : When in Program/Sampling mode, Global channel. When in Combination/Sequencer/Song Play mode, each IFX's channel. *3 : tt,ss = 00,02 : Arpeggiator Off/On = 00,0A : Arpeggiator Gate control = 00,0B : Arpeggiator Velocity control When in Program/Combination mode, Global channel message is valid. When in Sequencer/Song Play mode, current selected track's channel message is valid. Data Entry LSB value has no effect. tt,ss = 01,08 : Vibrato Rate tt,ss = 01,09 : Vibrato Depth tt,ss = 01,0A : Vibrato Delay tt,ss = 01,20 : Filter Cutoff tt,ss = 01,21 : Filter Resonance tt,ss = 01,63 : EG Attack Time tt,ss = 01,64 : EG Decay Time tt,ss = 01,66 : EG Release Time tt,ss = 14,kk : Drum Filter Cutoff * tt,ss = 15,kk : Drum Filter Resonance * tt,ss = 16,kk : Drum EG Attack Time * tt,ss = 17,kk : Drum EG Decay Time * tt,ss = 18,kk : Drum Coarse Tune * tt,ss = 19,kk : Drum Fine Tune * tt,ss = 1A,kk : Drum Volume * tt,ss = 1C,kk : Drum Panpot * tt,ss = 1D,kk : Drum Rev Send(Send2) * tt,ss = 1E,kk : Drum Cho Send(Send1) * * Only valid when Part Mode is Drum, MDrm1 - Mdrm4. kk: Drum Inst No. (0C - 6C = C0 - C8) Data Entry LSB value has no effect.
