INTRODUCTION
kortho Hot Quick Coder-D H215 AE Rev.: 10
1-2
1.4 Specifications
1.4.1 Coding unit
AgeneralimpressionofthecodingunitdimensionsisgivenfortheHotQuickCoderDinFig. 1.1

Thedimensionsofthecodingunitwithouthotrollsare:
Model HxWxD Printarea
HQC‐D 209x96.5x124mm10x24mm




Fig.
 1.1 CodingunitHQC‐D.
Thecodingunitsaredrivenbycompressedair,dryandoilfree,withapressureof0.4MPa.
1.4.2 Control box
Thedimensions(HxWxD)ofthecontrolboxare223x296x89mm.
Theelectricalrequirementsforthepowersupplyareavoltageof115or230VACandafrequencybetween50
and60Hz.Thetotalpowerconsumptionisthesumofthecontrolboxand
codingunitconsumption.Referto
section 5.1.
Allexternalequipmentthatisconnectedtothecontrolboxinterfacemustbedoubleinsulatedtoqualifythe
wholeinstallationasaseparatedextra‐lowvoltage(SELV,ClassII)system.
ThecontrolboxhasabespokehardwareuserinterfaceandhostI/O‐ports.
Theambienttemperaturemustbebetween5°Cand45°C,witharelativehumiditybetween10%and90%
(noncondensing).
1.5 Life span
Thelifespanoftheequipmentisfiveyears,undernormaluse.
Thelifespancanbenegativelyinfluencedbyimproper/uninformeduseoftheequipmentorimproper
maintenance,repairormodification.Noclaimsforguaranteeorcompensationfordamageswillbeaccepted
insuchinstances.
1.6 Shock & vibration
Thecontrolboxshouldbeinstalledinalowvibrationlocation.


