H215 AE
Rev.: 10 kortho Hot Quick Coder-D
5-1
5 INSTALLATION
5.1 Requirements
Providedbythecustomer:
Power:115or230VAC,50‐60Hz(refertoFig. 5.1fortotalpowerconsumption).
Atrigger‐signaloutputofthehostmachine(print).
Sufficientspaceforinstallationandoperation.
Compressedair,dryandoilfree,witha pressureof0.4MPa.
Optional:
Astop‐signalinputofthehostmachine(printeralarm).
Printerinhibit‐signaloutputofthehostmachine(stopprinter).
Abusy‐signalinputofthehostmachine(printerbusy).
Fig. 5.1 Powerconsumption/type.
Thetotalpowerconsumptionisthesumofthecontrolboxand
thecodingunitpowerconsumption.
Note:
Referto AppendixD,‘Connections’,‘Electricaldiagram,ControlboxI/O’fortheconnection
options.
5.2 Printer adaptation for 115VAC operation
Theprinterisstandardfittedwithfusesandheatingelementfor230VACoperation.Adaptationto115VAC
operationrequirestheexchangeoffuses(controlbox)andheatingelement(codingunit).RefertoFig. 5.2for
thefusevaluesandFig. 5.3fortheheatingelements/units
Fig. 5.2 Controlbox,fusevalues.
Refer
to AppendixDConnections,Power–I/Oboardforthelocationofthefuses
Fig. 5.3 Codingunit,heatingelements.
Referto AppendixCPartlists&illustrationsforthelocationoftheheatingelementandsensor.
SW1F1F2F3F4
230VAC 1AT 1,6AT 300mAT 500mAT
115 VAC 2AT 3,15AT 500mAT 500mAT
i
SW1 Part no. for
Qty Power
heating unit
230VAC 1x 150 W 814574
115VAC 1x 100 W 814672
Heating element
Name Type VA (max.).
Control box HQC-D 10
Coding unit HQC-D 100
