Kortho Hot Quick Coder-D Series User Manual

SAFETY
kortho Hot Quick Coder-D H215 AE Rev.: 10
4-2
Thewirecolourcodeforthesupplycableis: BROWNforLine(L)
BLUEforNeutral(N)
GREEN/YELLOWforProtectiveEarth(PE)
Wheninstallingorservicingtheequipmentensurethatthehostmachineisstopped.
4.3 Precautions before power-up
Checkateveryprinterpower‐upifalltheseconnectionsaresecured:
1. Themainspowerplug.(X1).
2. Theprintercable.(X2).
3. Thecable/conduit(X3/X4)betweenthecontrolboxandthecodingunit.
4.4 Precautions when opening the control box

Fig. 4.2 Attentionlabelforopeningthecontrolbox
Thecontrolboxhasanattentionlabel(Fig. 4.2)toalerttheusertoreadthemanualbeforeopeningthe
controlbox.
WARNING:
• ALWAYS
disconnectthepowertotheprinterbeforeremovinganyconnectorsorcovers:
• Switchtheprinteroff.
• Removetheplugfromthemainspowersupply.
• DONOT
operatestheprinterwhenanycoverisremoved.
• DONOTLEAVE
tools,screwsorotherpartsinsidethecontrolboxwhenre‐assemblingthe
equipment.
4.5 Anti-static precautions
Theprintedcircuitboardsarestaticsensitivedevices,whichcanbedamagediftheyaretouchedwithoutthe
necessaryelectrostaticdischarge(ESD)precautionsbeingtaken.TheESDprecautionsinvolvetheuseofa
groundedwriststrapand/orconductiveworkmat.
Duringinstallation,servicingandhandlingoftheprintedcircuitboards,
theprintedcircuitboardsmustbe
protectedfromelectrostaticdischarges.
