2.4 Text holder
ThetextholderoftheHQC‐Dslidesintoatextholderslotoftheprinthead.

Fig. 2.5 Textholder.
Thecharactersorclichéaremadeoutsiliconerubberandonthebacktheyhaveaspecialprofilewhichcanbe
pushedintothetextholder.Thehardnessofthesiliconerubberisimportanttogetagoodprint.
2.5 Mounting support

Fig. 2.6 StandardBracket.

1. Textholder
2. Removablehandle
1. Standardbracket
2. Standardplaten
