APPENDIX D CONNECTIONS

kortho Hot Quick Coder-D H215 AE Rev.: 10

D-2

Control Box Connectors

Item Descri

tion T

S1 Power switch Rocker switch

X1 Mains supply 5-ways, chassis plug

X2 Coding unit 8-ways, chassis socket

X3 Cable gland (input) PG9 gland

X4 Cable gland (output) PG9 gland

X5 Cable gland (Optional)

Fuses

Fuse ID 115 VAC 230 VAC

F1 2AT 1 AT

F2 3.15 AT 1.6 AT

F3 500m AT 300m AT

F4 500m AT 500m AT

814418, HQC-D, PCB Powersupply board
