2 TECHNICAL DESCRIPTION
2.1 The printer system
1
2
3
4
5
6

Fig. 2.1 Theprintersystem.
ThepictureFig. 2.1showsatypicalHotQuickCodersystem.Thesubstraterunsbetweenthecodingunitand
theplaten.Thehost(e.g.packagingmachinethatisconnectedtothecontrolbox)triggerstheprintertomakea
print.Aprintismadewhen
thecodingunitstampswiththetextholderonthesubstrate.Duringtheprint
processthehotrollwillberotatedsotheinktransfertothetextholderandtheusageofthehotrollwillbe
optimal.
Thetextcanbeappliedtoastationaryoramovingproduct.Themaximum
permittedproductspeedis60
m/min.Approx.250impressionsperminutecanbeproduced.
1. Controlbox
2. Substrate
3. Hotroll
4. Counterpressureplate
5. Codingunit
6. Bracket
