Kortho Hot Quick Coder-D Series User Manual

APPENDIX A SPECIFICATIONS
kortho Hot Quick Coder-D H215 AE Rev.: 10
A-2
Control box HQC-D
Coding unit HQC-D
Control box HQC-D
Specification units HQC-D
Weight [kg] 2,3
Dimensions Heigth [mm] 345
(with cable connectors and cable) Width [mm] 296
Depth [mm] 89
Main supply cable length [m] 2.5
Supply AC voltage (50/60 Hz) [V] 115 / 230
Power consumption [W] 10
Specification units HQC-D
Weight [kg] 2
Dimensions including Heigth [mm] 255
hotrolls and cable Width [mm] 163
Depth [mm] 124
Supply/Control cable length [m] 2,5
Print area (maximum) [mm]
12x24
Print rate, with full area (maximum) [n/min] 300
Print head temperature range [°C] 0-165
Compressed air, supply pressure range [MPa] 0,4
consumption at 0.4 Mpa [l/print] 0,04
Supply AC voltage (50/60 Hz) [V] 115 / 230
Power consumption [W] 100 / 150
Noise level [dB] 82
