APPENDIX C PART LISTS & ILLUSTRATIONS
kortho Hot Quick Coder-D H215 AE Rev.: 10
C-2
Control Box HQC-D

814532
Line Part no. Description Line Part no. Description
1 150007 STICKER DIM: 44X25MM 16 321704 TOP CONTROLBOX HP/HQC/KWP
2 152765 FILTER-REDUCTION UNIT 1/8 INCH 17 321732 BOTTOM CONTROLBOX HQC
3 152819 REDUCING COUPLING 1/8XM5 18 321758 COUPLING 1/8"
4 152877 HOSE NIPPLE M5X4MM 19 810682 POWER CORD HQC/HP
5 156517 PRESSURE GAUGE 0-10 BAR 1/8 IN 20 814418 POWER PCB HQC-D
6 158632 COUPLING NUT PG 9 21 814504 PCB FRONTPLATE BOX-D
7 160481 ROUND HEAD COUNTERSUNK SCREW 3X8 ST. 22 814771 CHASSISPART CONTROLBOX HQC-D
8 160564 3/2 MAGNETIC VALVE 1/8-1,5-24VDC 23 814825 CHASSISPART MAINS VOLTAGE. HQC-D
9 161557 KNEE JOINT 6X1/8" 24 814838 CORD BLUE HQC/HP
10 164974 PANEL CONTROL BOX HQC/HP 25 814841 CORD BLACK HQC/HP
11 165002 NAME PLATE CONTROLBOX HQC 26 814867 EARTH WIRE PCB HQC/HP-D
12 165098 COUPLING UNIT HOSE d=6,4 27 814879 CONTROLCABLE PCB HQC/HP-D
13 165101 SWITCH CONTROLBOX HQC/HP-D 28
14 165139 KNEE JOINT 6XM5 29
15 165142 DIMINISHING COUPLING 1/8X1/8K 30
Part no.:
CONTROL BOX HQC-D
