Kortho Hot Quick Coder-D Series - Coding Unit HQC-D Part List

APPENDIX C PART LISTS & ILLUSTRATIONS
kortho Hot Quick Coder-D H215 AE Rev.: 10
C-4
Coding unit HQC-D
814561
Line Part no. Description Line Part no. Description
1 118087 BALL BEARING 13/4X5 19 802518 PISTON ROD WITH PISTON QC
2 126572 COMPR.SPRING, LO=16,5; DM=4,0 20 802801 GUIDE BRACKET QC
3 151814 GASKETRING PISTON 16X9X2,1MM 21 802941 PLUG WITH BALL BEARING QC
4 153268 MTR. AIR TUBE 6/4-BLACK 22 803399 FORK QC
5 158127 COMPR.SPRING QC-M 23 809238 AIRCYLINDER COMPLETE HQC
6 304777 SPINDLE LONG 24 809254 HOUSING HQC
7 304789 SPINDLE SHORT 25 809295 HEATING RING HQC
8 304818 SCREW PRINTING HEAD 26 809419 DRIVING BLOCK HQC
9 304999 SPRING PRINTING HEAD 27 809422 CYLINDER BOTTOM HQC
10 305072 PISTON ROD QC 28 809842 TEXTPLATE HOLDER HQC
11 315614 BUFFER GEAR RACK 29 809855 PRINTING ASSY W/0 TEXTPL. HQC
12 315795 SHAFT HEATING UNIT HQC 30 810851 SPRING + HOLDER HQC
13 315808 SPRING HOLDER HQC 31 814574 HEATING UNIT HQC-D 230V
14 315935 BUFFER HOLDER HQC 32 814994 HEATING UNIT HQC-D 115V
15 316454 CAM HOLDER HQC 33
16 316651 COVER CAP HQC 34
17 316972 DISTANCE BUSH HEATING RING HQC 35
18 317587 SPRING HQC 36
CONTROL UNIT HQC-D
Part no.:
