Importing/Exporting Device Settings
You can select the type of device settings to export/import from/to the device.
To import or export the device settings:
1. In the Navigation pane, Select Device Settings. The General tab in the Device Settings
page appears (see Figure 18).
2. In the General Device Settings page, select the setting types to import or export.
▪ All without IP – Select all the settings, excluding the IP address.
▪ Streams – Select video, audio, IR, CEC and RS-232 settings.
▪ AV Settings Only – Select only Auto Switching EDID, video, and audio settings.
▪ All including IP – Select all the settings including the IP address.
3. When importing, do the following (when exporting, go to the next step):
▪ Click IMPORT. An Open file appears.
▪ Select the file to import (settings.tar.gz).
▪ Click Open to import the file.
4. To export settings, click EXPORT.
The settings file is created (settings.tar.gz).
The settings file is imported/exported.
Locating the Device
Locate the specific device in the system.
To locate the device:
1. In the Navigation pane, Select Device Settings. The General tab in the Device Settings
page appears (see Figure 18).
2. In the General Device Settings page, click APPLY next to Locate Device.
the located device NET and ON LEDs on the font panel flashes for 60 seconds.
The device is located in the system.
Managing the Firmware Version
To upgrade the firmware, view the date of the last upgrade, or rollback to the previous
firmware revision in case of a problem, see Upgrading Firmware on page 53.
