Kramer KDS-SW2-EN7 User Manual

Kramer Electronics Ltd.
KDS-SW2-EN7 – Protocol 3000
73
Function
Description
Syntax
Response
Parameters/Attributes
Example
X-MUTE?
Get mute ON/OFF
on a specific signal.
#X-MUTE?
<direction_type>.<port_format>.<po
rt_index>.<signal_type>.<index><C
R>
~nn@ X-MUTE
<direction_type>.<port_format
>.<port_index>.<signal_type>.
<index>,state<CR><LF>
<direction_type> – Direction of the
port:
IN – Input
OUT – Output
BOTH – Bi-directional
<port_format> – Type of signal on
the port:
HDMI
USB_C
ANALOG_AUDIO
<port_index> – The port number as
printed on the front or rear panel
1 – HDMI IN
2 – USB_C IN
1 – HDMI OUT
<signal_type> – Signal ID attribute:
VIDEO
AUDIO}
<index> – Indicates a specific
channel number when there are
multiple channels of the same type
state – OFF/ON (not case sensitive)
Get the mute the video on
HDMI OUT 1:
#X-MUTE?_out.hdmi.1.video.
1<CR>
X-PRIORITY
Set priority order.
#X-PRIORITY
<direction_type>.<port_format>.<po
rt_index>.<signal_type>,[<direction_
type>.<port_format>.<port_index>.<
signal_type> ,...]<CR>
~nn@X-PRIORITY
<direction_type>.<port_format
>.<port_index>.<signal_type>,[
<direction_type>.<port_format
>.<port_index>.<signal_type>
,...]<CR><LF>
<direction_type> – Direction of the
port:
IN – Input
OUT – Output
BOTH – Bi-directional }
<port_format> – Type of signal on
the port:
HDMI
USB_C
ANALOG_AUDIO
<port_index> – The port number as
printed on the front or rear panel
1 – HDMI IN
2 – USB_C IN
1 – HDMI OUT
<signal_type> – Signal ID attribute:
VIDEO
AUDIO
Set video priority is 3,2,1
#X-PRIORITY
out.hdmi.1.video,[in.usb_c.3.
video,in.hdmi.2.video,
in.hdmi.1.video]<CR>
X-PRIORITY?
Get priority order.
#X-PRIORITY?
<direction_type>.<port_format>.<po
rt_index>.<signal_type><CR>
~nn@X-PRIORITY
<direction_type>.<port_format
>.<port_index>.<signal_type>,[
<direction_type>.<port_format
>.<port_index>.<signal_type>
,...]<CR><LF>
<direction_type> – Direction of the
port:
IN – Input
OUT – Output
BOTH – Bi-directional }
<port_format> – Type of signal on
the port:
HDMI
USB_C
ANALOG_AUDIO
<port_index> – The port number as
printed on the front or rear panel
1 – HDMI IN
2 – USB_C IN
1 – HDMI OUT
<signal_type> – Signal ID attribute:
VIDEO
AUDIO
Get video priority
#X-PRIORITY?
out.hdmi.1.video<CR>
X-ROUTE
Send routing
command.
NOTE: It is
recommended to use
the command
#SIGNALS-LIST to
get the list of all
signal IDs available
in the system and
which can be used in
this command.
Video 1 is the default
port in this command
and is implied even if
not written:
#X-ROUTE
out.sdi.5,in.sdi.1<CR
>
is interpreted as:
#X-ROUTE
out.sdi.5.video.1,in.s
di.1.video.1<CR>
This is an Extended
Protocol 3000
command.
Brackets ‘[‘ and ‘]’
are reserved
Protocol 3000
characters that
define a list of
parameters as in
[a,b,c,d].
#X-ROUTE
[<direction_type1>.<port_type1>.<p
ort_index1>.<signal_type1>.<index1
>,...],<direction_type2>.<port_type2
>.<port_index2>.<signal_type2>.<in
dex2><CR>
~nn@X-ROUTE
[<direction_type1>.<port_type1
>.<port_index1>.<signal_type1
>.<index1>,…],<direction_type
2>.<port_type2>.<port_index2
>.<signal_type2>.<index2><C
R><LF>
The following attributes comprise
the signal ID:
<direction_type> – Direction of the
port:
IN – Input
OUT – Output
BOTH – Bi-directional (e.g. for RS-
232)
<port_format> – Type of signal on
the port:
HDMI
HDBT
ANALOG_AUDIO
RS-232
IR
USB_A
USB_B
STREAM
<port_index> – The port number as
printed on the front or rear panel
<signal_type> – Signal ID attribute:
VIDEO
AUDIO
RS232
IR
USB
<index> – Indicates a specific
channel number when there are
multiple channels of the same type
Route HDMI IN 2 to HDMI
OUT 1:
#X-ROUTE
out.hdmi.1.video.1,in.hdmi.2.
video.1<CR>
