Kramer KDS-SW2-EN7 User Manual

Kramer Electronics Ltd.
KDS-SW2-EN7 – Protocol 3000
74
Function
Description
Syntax
Response
Parameters/Attributes
Example
X-ROUTE?
Get routing status.
NOTE: It is
recommended to use
the command
#SIGNALS-LIST to
get the list of all
signal IDs available
in the system and
which can be used in
this command.
VIDEO.1 are the
default
<signal_type> and
<index> in this
command and are
implied even if not
written:
#X-ROUTE
out.sdi.5,in.sdi.1<CR
>
is interpreted as:
#X-ROUTE
out.sdi.5.video.1,in.s
di.1.video.1<CR>
This is an Extended
Protocol 3000
command.
#X-ROUTE?
<direction_type1>.<port_type1>.<po
rt_index1>.<signal_type1>.<index1>
<CR>
~nn@X-ROUTE
<direction_type1>.<port_type1
>.<port_index1>.<signal_type1
>.<index1>,<direction_type2>.
<port_type2>.<port_index2>.<s
ignal_type2>.<index2><CR><L
F>
The following attributes comprise
the signal ID:
<direction_type> – Direction of the
port:
IN – Input
OUT – Output
BOTH – Bi-directional (e.g. for RS-
232)
<port_format> – Type of signal on
the port:
HDMI
HDBT
ANALOG_AUDIO
RS-232
IR
USB_A
USB_B
STREAM
<port_index> – The port number as
printed on the front or rear panel
<signal_type> – Signal ID attribute:
VIDEO
AUDIO
RS232
IR
USB
<index> – Indicates a specific
channel number when there are
multiple channels of the same type
Get the routing status for
HDMI out:
#X-ROUTE?
out.hdmi.1.video.1<CR>
