26 VS-42UHD - Operating the VS-42UHD Remotely via the Web Pages
The VS-42UHD allows you to program the general purpose buttons on remote
modules. The table shows the functionality defined for each button. The options
are:
• HDMI—selects one of the four inputs
• Echo—allows a connected controller to be programmed to perform a variety
of tasked triggered by the user buttons, such as, room control, (lights, screen,
and so on)
• Out 1—step-in current input to output 1
• Out 2—step-in current input to output 2
Note: These settings are per input and remain valid even if the remote SID-X3N is
exchanged for another SID-X3N.
Up to three of the Echo, Out 1 and Out 2 buttons can be active at the same time.
8.2.3 Using Test Patterns as Video Inputs
You can use one of four built-in, video test patterns as a video Input.
Figure 15: Test Pattern Tab
