42 VS-42UHD - Protocol 3000
13.2 Kramer Protocol 3000 Syntax
The Kramer Protocol 3000 syntax uses the following delimiters:
• CR = Carriage return (ASCII 13 = 0x0D)
• LF = Line feed (ASCII 10 = 0x0A)
• SP = Space (ASCII 32 = 0x20)
Some commands have short name syntax in addition to long name syntax to
enable faster typing. The response is always in long syntax.
The Protocol 3000 syntax is in the following format:
• Host Message Format:
Start
Address (optional)
Body
Delimiter
#
Device_id@
Message
CR
• Simple Command – Command string with only one command without
addressing:
Start
Body
Delimiter
#
Command
SP
Parameter_1,Parameter_2,…
CR
• Command String – Formal syntax with command concatenation and
addressing:
Start
Address
Body
Delimiter
#
Device_id@
Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3
Parameter3_1,Parameter3_2,…|…
CR
• Device Message Format:
Start
Address (optional)
Body
Delimiter
~
Device_id@
Message
CR LF
• Device Long Response – Echoing command:
Start
Address (optional)
Body
Delimiter
~
Device_id@
Command
SP
[Param1 ,Param2 …] result
CR LF
