VS-42UHD – Contents i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions DC 2
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Using the IR Transmitter 5
3.2 Defining the VS-42UHD 4x2 HDMI Matrix Switcher 6
4 Connecting the VS-42UHD 8
4.1 Connecting a Serial Controller via RS-232 9
4.2 Connecting to the VS-42UHD via Ethernet 9
4.3 Connecting the Remote Contact-Closure Switches 12
5 Principles of Operation 14
5.1 Automatic Signal Detection 14
5.2 Input Switching Modes 14
5.3 EDID Operation 15
5.4 Step-in Functionality 15
6 Operating the VS-42UHD 4x2 HDMI Matrix Switcher 16
6.1 Switching an Input to an Output 16
6.2 Acquiring an EDID from an Output 16
6.3 Muting and Unmuting the Outputs 17
6.4 Locking and Unlocking the Front Panel Buttons 18
6.5 Generating a Test Pattern 18
7 Configuring and Maintaining the VS-42UHD 19
7.1 Setting the DIP-Switches 19
7.2 Resetting the VS-42UHD to Factory Default Settings 20
7.3 Upgrading the Firmware 20
8 Operating the VS-42UHD Remotely via the Web Pages 21
8.1 Browsing the VS-42UHD Web Pages 21
8.2 Routing Page 23
8.3 EDID Page 27
8.4 Device Setting Page 29
8.5 Firmware Upgrade Page 30
8.6 About Us Page 31
9 Wiring the Twisted Pair RJ-45 Connectors 32
10 Technical Specifications 33
11 Default Communication Parameters 34
12 Default EDID 35
13 Protocol 3000 39
13.1 Understanding Protocol 3000 40
13.2 Kramer Protocol 3000 Syntax 42
13.3 Protocol 3000 Commands 43
