Kramer VS-88H2

Kramer Electronics Ltd.
VS-88H2 – Operating VS-88H2 via Front Panel Buttons
18
2. Press a flashing IN (PATTERN) Button (for example, input 3)
The corresponding 7-segment display LED flashes.
3. Press an illuminated OUT (MUTE) Button (for example, output 6).
The flashing 7-segment display LED shows the selected input number and after
selecting the HDMI audio OUT the port number appears (6).
On the 7-segment display:
• “.” under an output number (when in D-AUDIO mode) indicates that arc is enabled on
the corresponding output (outputs 1 and 6 to 8 in this example).
• “0” under an output number indicates that the audio output is muted.
The HDMI OUT 6 ARC audio signal is routed to ARC input 3.
Exit ARC mode by pressing D-AUDIO or VIDEO buttons.
Muting/Unmuting an Output Audio Signal
You can mute/unmute an audio signal and a video signal separately.
To mute/unmute an audio signal:
1. Press D-AUDIO .
The D-AUDIO button illuminates.
2. Press an OUT (MUTE) button (1 to 8).
Press ALL (instead of an output button) to mute/unmute all the outputs. All the
7-segment display LEDs flash.
3. Press MUTE/PATTERN .
The audio signal is muted/unmuted on the output. A muted output appears as “0” on the
7-segment display.
Muting/Unmuting an Output Video Signal
To mute/unmute a video signal:
1. Press VIDEO .
The button illuminates and the 7-segment LED Display shows the current IN-OUT
video status.
2. Press an OUT (MUTE) button (1 to 8).
The 7-segment display LED, under the selected output, flashes.
Press ALL (instead of an output button) to mute/unmute all the outputs. All the
7-segment display LEDs flash.
3. Press MUTE/PATTERN .
The audio signal is muted/unmuted on the output. A muted output appears as “0” on the
7-segment display.
