VS-88H2 – Using Embedded Web Pages
31
Setting Output HDCP Status
This section contains information on setting output HDCP status.
To set output HDCP status:
1. In the Navigation pane, click Switching.
The Switching page appears (Figure 18).
2. Select the AFV tab.
The Audio-follow-video tab is displayed (Figure 18).
3. Click on an output button (Figure 19).
The output settings window appears (Figure 20).
4. Select HDCP dropdown box and set HDCP support to Follow input HDCP, Support
HDCP 1.4, or Support HDCP 2.2.
Output ( ) HDCP icon appears (2nd icon on button) when output is without HDCP.
Output ( ) HDCP icon appears (2nd icon on button) when output is HDCP 1.4.
Output ( ) HDCP icon appears (2nd icon on button) when output is HDCP 2.0.
