Kramer VS-88H2

Kramer Electronics Ltd.
VS-88H2 – Protocol 3000 Commands
77
Function
Description
Syntax
Parameters/Attributes
Example
TUNNEL-
CTRL
LEGACY COMMAND.
Send an
asynchronous
command to a remote
Step-in equipment.
COMMAND
#TUNNEL-CTRLio_mode,io_index,cmd_name<CR>
FEEDBACK
None
io_mode – Input/Output
0 – Input
1 – Output
io_index – Number that indicates
the specific input or output port:
1-N (N= the total number of input or
output ports)
cmd_name – Command to send to
the Step-in client
LEGACY COMMAND:
#TUNNEL-CTRL1,1,1<C
R>
UART
Set com port
configuration.
In the FC-2x the
serial port is
selectable to RS-232
or RS-485 (usually
serial port 1).
If Serial is configured
when RS-485 is
selected, the RS-485
UART port
automatically
changes.
The command is
backward compatible,
meaning that if the
extra parameters do
not exist, FW goes to.
RS-232.
Stop_bits 1.5 is only
relevant for 5
data_bits.
COMMAND
#UARTcom_id,baud_rate,data_bits,parity,stop_bits_mode,s
erial_type,485_term<CR>
FEEDBACK
~nn@UARTcom_id,baud_rate,data_bits,parity,stop_bits_mod
e,serial_type,485_term<CR><LF>
com_id – 1 to n (machine
dependent)
baud_rate – 9600 - 115200
data_bits – 5-8
parity – Parity Type
0 – No
1 – Odd
2 – Even
3 – Mark
4 – Space
stop_bits_mode – 1/1.5/2
serial_type – 232/485
0 – 232
1 – 485
485_term – 485 termination state
0 – disable
1 – enable
(optional - this exists only when
serial_type is 485)
Set baud rate to 9600, 8
data bits, parity to none and
stop bit to 1:
#UART?1,9600,8,node
,1<CR>
UART?
Get com port
configuration.
In the FC-2x the
serial port is
selectable to RS-232
or RS-485 (usually
serial port 1).
If Serial is configured
when RS-485 is
selected, the RS-485
UART port
automatically
changes.
The command is
backward compatible,
meaning that if the
extra parameters do
not exist, FW goes to.
RS-232.
Stop_bits 1.5 is only
relevant for 5
data_bits.
COMMAND
#UART?com_id<CR>
FEEDBACK
~nn@UARTcom_id,baud_rate,data_bits,parity,stop_bits_mod
e,serial_type,485_term<CR><LF>
com_id – 1 to n (machine
dependent)
baud_rate – 9600 - 115200
data_bits – 5-8
parity – Parity Type
0 – No
1 – Odd
2 – Even
3 – Mark
4 – Space
stop_bits_mode – 1/1.5/2
serial_type – 232/485
0 – 232
1 – 485
485_term – 485 termination state
0 – disable
1 – enable
(optional - this exists only when
serial_type is 485)
Get baud rate to 9600, 8
data bits, parity to none and
stop bit to 1:
#UART?1<CR>
VERSION?
Get firmware version
number.
COMMAND
#VERSION?<CR>
FEEDBACK
~nn@VERSIONfirmware_version<CR><LF>
firmware_version –
XX.XX.XXXX where the digit groups
are: major.minor.build version
Get the device firmware
version number:
#VERSION?<CR>
VID
LEGACY COMMAND.
Set video switch state.
The GET
command identifies
input switching on
Step-in clients.
The SET command is
for remote input
switching on Step-in
clients (essentially via
by the Web).
This is a legacy
command. New Step-
in modules support
the ROUTE
command.
COMMAND
#VIDin_id>out_id<CR>
FEEDBACK
~nn@VIDin_id>out_id<CR><LF>
in_id – Indicates the ID of the
input:
1-n (n= the total number of inputs)
> – Connection character between
in and out parameters
out_id –Output number
* for all outputs
Switch HDMI IN 1 to HDMI
OUT 3:
#VID1>3<CR>
