Kramer VS-88H2 User Manual

Kramer Electronics Ltd.
VS-88H2 – Defining the Matrix Switcher
6
#
Feature
Function
IN (PATTERN)
SELECTOR
Buttons
Press to select the input to switch to the output that was previously selected
(also used for storing machine setups in the STO-RCL modes and for
selecting a pattern in the Pattern mode).
In the ARC mode, all inputs can operate as audio outputs (see Operating in
ARC Mode on page 17).
OUT (MUTE)
SELECTOR
Buttons
Press to select an output to which the input is routed. Also used for storing
machine presets.
In the ARC mode, each output can operate as an audio input (see Operating
in ARC Mode on page 17).
MUTE/PATTERN
Button
Press to view the current pattern status and select the output/s to which a
pattern is routed.
Press to mute audio or video on a selected output when D-AUDIO and/or
VIDEO buttons are pressed (lit).
ALL Button
Press to perform an action on all outputs (for example, setting Mute mode,
Pattern mode and so on).
For switching, press ALL and then a specific IN button to route the selected
input to all outputs. For example, press ALL and then IN 2 to route input 2 to
all the outputs.
STO Buttons
Press STO to store the current switching setting to a preset button.
RCL Buttons
Press RCL to recall the switching setting from a preset button.
ARC Button
Press to set ARC mode on the inputs (see Operating in ARC Mode on
page 17).
D-AUDIO Button
Press to enable digital audio routing. When pressed together with VIDEO, the
digital audio is routed together with the video signal.
VIDEO Button
Press to select video inputs. When pressed together with D-AUDIO, video is
switched together with audio.
LOCK Button
Press and hold (for about 3 seconds) to toggle locking/releasing of the front
panel buttons.
Press to save the following setups: HDCP (On/Off), ARC, Fast Switch and
Switch mode.
EDID Button
Press to capture the EDID.
OUTPUT/INPUT
7-segment LED
Display
Displays the selected inputs switched to the outputs (marked above each
input).
1
2
3
4
5
6
7
8
9
10
11
12

Kramer VS-88H2 Specifications

General

HDCP	Yes
HDCP version	1.4/2.2
Product type	AV matrix switcher
Audio channels	7.1
Control type	Buttons
Housing color	Black
USB connector type	Mini-USB, USB Type-A
USB ports quantity	2
HDMI input ports quantity	8
Ethernet LAN (RJ-45) ports	1
Display type	LCD
Input current	0.6 A
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	- W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	RoHS
Cables included	AC

Weight and Dimensions

Depth	183 mm
Width	436.4 mm
Height	43.6 mm
Weight	2400 g
Package depth	330 mm
Package width	525 mm
Package height	107 mm
Package weight	3300 g
