23 TECHNICAL DATA 182

Screw, rear ABS sensor wheel M6 8 Nm (5.9 lbf ft) –

Screw, rear fender M6 7 Nm (5.2 lbf ft) –

Screw, retaining bracket, EFI control

unit

M6 7 Nm (5.2 lbf ft) –

Screw, seat lock M6 7 Nm (5.2 lbf ft) –

Screw, shift lever linkage M6 11 Nm (8.1 lbf ft) Loctite

243™

Screw, side cover M6 6 Nm (4.4 lbf ft) –

Screw, side cover on front fairing M6 7 Nm (5.2 lbf ft) –

Screw, voltage regulator M6 7 Nm (5.2 lbf ft) –

Screw, voltage regulator holder M6 11 Nm (8.1 lbf ft) –

Screw, wheel speed sensor holder M6 7 Nm (5.2 lbf ft) –

Screw, windshield M6 7 Nm (5.2 lbf ft) –

Fitting, engine mounting bracket M8 48 Nm (35.4 lbf ft) –

Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, chain guard M8 11 Nm (8.1 lbf ft) –

Screw, engine bearer on frame M8 24 Nm (17.7 lbf ft) –

Screw, foot brake lever M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, front brake disc M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, front wheel spindle M8 26 Nm (19.2 lbf ft) –

Screw, fuel tank attachment, rear, on

frame

M8 17 Nm (12.5 lbf ft) –

Screw, horn M8 9 Nm (6.6 lbf ft) –

Screw, main silencer M8 24 Nm (17.7 lbf ft) –

Screw, passenger footrest bracket M8 20 Nm (14.8 lbf ft) Loctite

243™
