23 TECHNICAL DATA 183
Screw, rear brake disc M8 25 Nm (18.4 lbf ft) Loctite
®
243™
Screw, retaining bracket on fuel tank M8 13 Nm (9.6 lbf ft)
Screw, shift lever M8 17 Nm (12.5 lbf ft) Loctite
®
243™
Screw, top triple clamp M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8x1 30 Nm (22.1 lbf ft) Loctite
®
204™
Nut, rear sprocket screw M8x1.25 27 Nm (19.9 lbf ft) Loctite
®
243™
Banjo bolt, brake line M10 24 Nm (17.7 lbf ft)
Fitting side stand M10 35 Nm (25.8 lbf ft) Loctite
®
243™
Remaining nuts, chassis M10 50 Nm (36.9 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Fitting, shock absorber, bottom M10x1.25 50 Nm (36.9 lbf ft)
Nut, turn signal M10x1.25 6 Nm (4.4 lbf ft)
Screw, front footrest bracket / engine
bearer
M10x1.25 47 Nm (34.7 lbf ft)
Screw, side stand bracket M10x1.25 33 Nm (24.3 lbf ft) Loctite
®
243™
Stud, rear sprocket M10x1.25 50 Nm (36.9 lbf ft)
Nut, rear wheel spindle M14x1.5 90 Nm (66.4 lbf ft)
Nut, swingarm pivot M14x1.5 100 Nm (73.8 lbf ft)
Screw, steering head, top M16x1.5 53 Nm (39.1 lbf ft) Loctite
®
204™
Lambda sensor M18x1.5 19 Nm (14 lbf ft)
Swingarm bearing adjusting ring M22x1 Tighten and ensure that there
is no play
