11. - Maintenance and storage
FC3160-3560-4060 TCD
95
KN284EGB_A
Mower conditioner
- After replacing the last knife, check that the
tool has been removed and put away.
Disc replacement
- Place a wooden wedge (1) between two discs to
stop them from moving.
- Remove the 4 bolts (2) and their conical washers.
- Remove disc cover (1).
- Remove the disc (2).
- Replace worn or damaged disk with a new disk.
