11. - Maintenance and storage
FC3160TCD-3560TCD-4060TCD
103
KN284DGB B
Mower conditioner
- Reinstall knives on the disk.
- Repeat procedure on the second disk.
- Reinstall spring plate (8).
- Fit disc (2).
- Torque bolts to (4) (M12 x 30):
• Torque: 12.5 daN m (92.2 lbf ft).
The lifter service life can be doubled by inverting
them with those of a disk rotating in the opposite
direction.
Proceed with inversion before they are too much
worn.
