FC3160TCD-3560TCD-4060TCD
106
11. - Maintenance and storage
KN284DGB B
Mower conditioner
- Rotate adjustment screw (1) to release pressure
on the torsion bar.
1
- Extract torsion bar (1) from its housing by pulling
on screw (2).
2
1
- Rotate adjustment screw while pushing on the
torsion bar until reaching the following spline:
• Rotate in direction (a) if the cutter bar is too light
and in direction (b) if the cutter bar is too heavy.
1
