FC3160TCD-3560TCD-4060TCD
112
11. - Maintenance and storage
KN284DGB B
Mower conditioner
- Remove the damaged bolt part (1).
- Rotate cutter bar by hand to place hole (2)
opposite the next nut.
2
1
Use exclusively KUHN original parts.
5 spare M8 x 31 bolts are supplied with the
machine.
Check the shearing bolt class.
Machine Shearing bolt class
FC3160TCD
10.9FC3560TCD
FC4060TCD
- Fit the new screw.
• Torque: 2.5 daNm (18.5 lbf ft)
