FC3160TCD-3560TCD-4060TCD
94
11. - Maintenance and storage
KN284DGB B
Mower conditioner
Fitting
Knives can be turned over on the same disc to use
the other cutting edge or replaced. On each knife,
an arrow indicates the disc's direction of rotation.
- Pivot special tool downwards to free spring plate
from screw head.
- Make sure that the securing nut and bolt are in
good condition and if necessary, replace them.
• Torque: 12 daN m (89 lbf ft).
Dull knives require more horse power and have a
negative effect on the cut quality.
Refer to self-adhesive fitted on the machine
to check the codes and dimensions of the
knives.
- Pivot special tool downwards to free spring plate
from screw head.
- Insert the new knife on the screw head.
