KUHN GMD16 - 5. Machine specifications; 5.1 Description and glossary

GMD16-GMD20
34
5. - Machine specifications
KN225BGB_A
Disc mower
5. Machine specifications
5.1 Description and glossary
0
1 : Cutterbar 2 : Front guard
3 : Check chain 4 : Hitch pin
5 : Lift cylinder 6 : Compensating spring
7 : Upper coupling yoke 8 : Safety breakback
9 : Parking stand 10 : Disk
11 : Guard lock 12 : Unlocking handle
13 : Swath wheel
1
2
3
5
6
7
8
9
10
11
4
13
12
