GMD16-GMD20
74
10. - Maintenance and storage
KN225BGB_A
Disc mower
Checking the tension
- Exert a force of 3.5 daN on the belt:
• The deflection H must not exceed 10 mm (0.39’’).
10.3.2 Breather plug checking and cleaning
From the working position:
- Remove breather plug (1) and its seal.
- Clean and check breather plug for good
functioning (1).
- Reinstall breather plug (1) and its seal.
H
1
