KUHN GMD16 - 6.2.5 Hydraulic connections; 6.2.6 Electrical connection; 6.2.7 Fit check chain

GMD16-GMD20
46
6. - Putting into service
KN225BGB_A
Disc mower
- Pull on handle (1) to unlock parking stand (2) (a).
- Raise and lock parking stand (b).
- Lock tractor lower link stabilisers.
6.2.5 Hydraulic connections
- Connect hydraulic hose (1) of the transport/work
cylinder to a single acting valve with float position.
6.2.6 Electrical connection
6.2.7 Fit check chain
a
b
2
1
When optional equipment is used, follow
specific procedures mentioned in the related
section:
• Optional equipment / Manual
hydraulic cutter bar lift pump.
1
2
When optional equipment is used, follow
specific procedures mentioned in the related
section:
• Optional equipment / Lighting and
signalling.
See section: Putting into service / Coupling and
uncoupling / Adjusting the machine / Frame
height and check chains.
